11 SETUP/MAINTENANCE
Invacare
3G Storm Series® 106 Part No 1143151
FIGURE5 Disconnecting/Connecting Battery Cables - Group 24 Batteries
Locknut
NEGATIVE (-) Battery
Terminal/Post
RED POSITIVE (+) Battery Cable
Fuse Mounting Screw
Locknut
Mounting Screw
Top View of Battery
Black NEGATIVE (-)
Battery Cable
POSITIVE (+) Battery
Terminal/Post
DETAIL “A” -
CONNECTING
CABLES TO
TERMINALS
DETAIL “B” - ONE
CONNECTOR
BATTERY BOX
BLACK Battery Terminal Cap
RED Battery
Terminal Cap
Black NEGATIVE (-)
Battery Cable
One Connector
Battery Box Top
RED
POSITIVE (+)
Battery Cable
NEGATIVE (-) Battery
Terminal/Post
Top View of Battery
POSITIVE (+) Battery
Terminal/Post
