11 SETUP/MAINTENANCE
Part No 1143151
107 Invacare 3G Storm Series®
FIGURE6 Disconnecting/Connecting Battery Cables - Group 24 Batteries
Two Connector Elevate Battery Box
NEGATIVE (-) Battery
Terminal/Post
Top View of Battery
POSITIVE (+) Battery
Terminal/Post
Black NEGATIVE (-)
Battery Cable
BLACK Battery
Terminal Cap
RED POSITIVE (+)
Battery Cable
Two Connector Non-Elevate Battery Box
Two Connector Battery
Box Top
RED Battery
Terminal Cap
RED POSITIVE (+)
Battery Cable
RED Battery
Terminal Cap
BLACK Battery
Terminal Cap
Black NEGATIVE (-)
Battery Cable
NEGATIVE (-) Battery
Terminal/Post
POSITIVE (+) Battery
Terminal/Post
Top View of
Battery
Two Connector
Battery Box Top
