11 SETUP/MAINTENANCE
Invacare
3G Storm Series® 92 Part No 1143151

WARNING: FOR WHEELCHAIRS USING GP24 BATTERIES
Batteries with terminal configuration (POSITIVE on the right and NEGATIVE on the left) as shown below MUST be used.
Batteries that have the reverse terminal configuration MUST not be used - otherwise injury and damage may occur.
Terminals MUST have a cross hole in them as shown below.
DETAIL “A” -
TERMINAL CROSS
HOLES
Terminal Cross Holes
POSITIVE (+) Battery
Terminal/Post
NEGATIVE (-)
Battery Terminal/Post
POSITIVE (+)
Battery Terminal/Post
NEGATIVE (-)
Battery Terminal/Post
GP24
DO NOT Use
GP24
