Invacare Comet Series User Manual

Comet
Batterycapacity:
<25%
Reduceddrivingrange.
Rechargethebatteriesattheend
ofyourjourney.
Batterycapacity:
<20%
Batteryreserve=severely
restricteddrivingrange.
Rechargebatteriesimmediately!
(2)(3)(4)(5)(6)(7)(8)
Batterycapacity
>80%
<80%
<65%
<50%
<35%
<25%
<20%
Operatingconsole(LCDversion)
Arrangement
A
Statusdisplay
B
Switchingon/offcurvecontrol(reductionofspeed
whendrivinginacurve)
C
Hazardlights
D
Horn
E
Left-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
F
Speedcontroldial
G
Right-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
H
Lighting
I
Lowspeedmode
J
Setting
K
Drivelever
Statusdisplay
A
Speedindication
B
Faultindication
C
Curvecontrolindication
D
Maintenanceindication
1
E
Headlightindication
F
Leftturnindication
G
Settingsshown:ODO,TRIP ,TEMP ,TIME
H
Rightturnindication
I
Batterystatus
J
Lowspeedselectionindication
1
Ifthissymbolstartsashingforoneminuteeverytime
thescooterisswitchedon,contactyourprovider.
Batteryindicationgauge
Lowbatteryindication:Everytimethescooteris
activatedoratworkwhenbatterycapacityislower
than25%,theelectronicsystemwillbeepthree
times.
Overdischargeprotection:afteracertaindrivetime
onreservebatterypowertheelectronicsystem
switchesthedriveoffautomaticallyandbringsthe
scootertoastandstill.Ifyoudonotdriveyour
scooterforawhilethebatterieswill"recuperate"
andallowafurther,butshort,journey.However,
afteraverybriefjourneythebatteryreservesymbol
willilluminateagainandtheelectronicsystemwill
beepthreetimes.Thisprocedureleadstobattery
damageandshouldbeavoidedifpossible!
Batterycapacity:
<25%
Reduceddrivingrange.
Rechargethebatteriesattheend
ofyourjourney.
Batterycapacity:
<20%
Batteryreserve=severely
restricteddrivingrange.
Rechargebatteriesimmediately!
>80%<80%<65%<50%<35%<25%<20%
Enteringsetup(LCDDisplay)
ThischapterappliesformobilitydeviceswithLCD
display.
161603798-B

Invacare Comet Series Specifications

General

Ground Clearance	2.5 inches (6.35 cm)
Turning Radius	49 inches (124.5 cm)
Seat width	17 inches (43.2 cm)
Weight Capacity	300 lbs (136 kg)
Max. user weight	300 lbs (136 kg)
