6 DEALER SECTION - PACKAGING, HANDLING, AND SET-UP
Invacare
®
G5510 Bed 56 Part No 1180159
FIGURE 11 Installing/Removing Mattress Keepers
6.7 Connect Power Supply
1. Plug power supply into bus cable port marked power.
FIGURE 12 Connect Power Supply
Detail “A” - Location
Mattress Keeper
Mattress Keeper
Mattress Keeper
End Slat
Detail “B”
Detail “C”
Mattress Keeper
End Slat
Mattress Keeper
Ta b
End Slat
Bus Cable
Power Supply
