The joystick battery discharge indicator and the Remote Programmer give indications of
the type of fault or error detected by the control module. When a fault is detected, the
chair will stop and not drive. For the SPJ-80 joysticks, the last two red bars of the BDI
will begin to flash followed by a pause. An error code and a quick description of the
fault will begin to scroll across the Remote Programmer display. If multiple faults are
found, only the first fault encountered by the control module program will be displayed.
Refer to the Power Chair Service Manual for detailed trouble shooting and repair
instructions. Below is a list of the diagnostics codes and their causes:
NO. OF FLASHES DIAGNOSTICS CODE CAUSE OF ERROR
1 E 01 Joystick Reverse – too large
1 E 02 Joystick Forward – too large
1 E 03 Joystick Right – too large
1 E 04 Joystick Left – too large
2 E 05 M1 current sense amp – high
2 E 06 M1 current sense amp – low
2 E 07 M2 current sense amp – high
2 E 08 M2 current sense amp – low
3 E 09 M1 motor circuit open
3 E 10 M2 motor circuit open
4 E 11 Neutral reference voltage – high
4 E 12 Neutral reference voltage – low
5 E 13 Battery voltage – high
5 E 14 Battery voltage – low
5 E 28 Battery charger connected
6 E 15 M1 power stage
6 E 16 M2 power stage
7 E 17 Neutral calibration SPD
7 E 18 Neutral calibration DIR
7 E 19 Joystick calibration – Forward
7 E 20 Joystick calibration – Reverse
7 E 21 Joystick calibration – Left
7 E 22 Joystick calibration – Right
7 E 23 RAM fault detected
7 E 24 M1 null offset
7 E 25 M2 null offset
7 E 26 Configuration register not
programmed
7 E 27 EPROM error detected
7 E 30 CPU EEPROM fault detected
7 E 31 Isolation Relay is faulty
1 E 32 System communications error.
Check connectors.
1 E 33 Network Fail bit
7 E 35 Control Neuron failure
7 E 36 Current Sense not calibrated
7 E 37 Motor Voltages Not Matched
