Invacare MK5 NX User Manual

SECTION 6—REMOTE PROGRAMMER
MK
5
™NX™Electronics 28 Part No 1110532
SECTION 6—REMOTE
PROGRAMMER
Overview
NOTE: For this procedure, refer to FIGURE 6.1.
The Remote Programmer is the information center of the control module. Through simple
key sequences, the Remote Programmer allows modification of the performance
characteristics, gives diagnostics information for troubleshooting and permits calibration
of the control module.
NOTE: The joystick power switch must be on for the programmer to operate. If the programmer
displays “Communication Error”, disconnect the programmer and reconnect it with the joystick
turned on.
FIGURE 6.1 Overview
SAVE Key
SELECT
Key
POWER Key
MENU Key
DOWN
Key
UP Key
LCD Display
Remote
Programmer
Remote
Programmer
To Joystick
Multi-Function
Charger Input
Multi-Function
Charger Input
SPJ
Joystick
CSPJ
Joystick
SPJ+ w/ACC
Joystick
SPJ+
Joystick
