SECTION 7—PROGRAMS
Part No 1110532 31 MK
5
™NX™Electronics
SECTION 7—PROGRAMS
Program Settings
WARNING
DO NOT mismatch a program with the wheelchair type (i.e. selecting a rear wheel
drive program for a center wheel drive wheelchair or vice versa). Confirm that the
settings and program match the wheelchair before selecting or saving. Otherwise,
unintended and unsafe joystick control of the wheelchair will occur, possibly result-
ing in serious bodily injury.
The program settings are available as a reference point for initial set-up of the wheelchair,
for final user setting or whenever major changes have been made in the performance and
a known starting point needs to be reestablished. Confirm that the settings and program
match the wheelchair before selecting or saving.
Three programs are available.
1. Select PROGRAMS from the main menu to display the standard value menu.
2. Press or and then the SELECT key to select the standard program to be placed
in the temporary memory.
3. Press the SAVE key to store the program into a selected drive.
4. Make changes to specific functions as needed.
The general capabilities of the standard programs are listed below:
NOTE: If the default settings in the following tables are not desired, they will need to be changed
manually. Performance Adjustments
on page 21.
PROGRAMMER READS DRIVE TYPE MOTOR TYPE
RWD Rear Wheel Drive 2-Pole
RWD Rear Wheel Drive 4-Pole
ATM Rear Wheel Drive 2-Pole
CWD Center Wheel Drive 2-Pole
MWD Center Wheel Drive 2-Pole
To Next Page
