SECTION 7—PROGRAMS
MK
5
™NX™Electronics 32 Part No 1110532
DEFAULT SETTINGS FOR NX
FUNCTION PROGRAM 1 PROGRAM 2 PROGRAM 3
RWD 2-POLE RWD 4-POLE CWD 2-POLE
FORWARD SPEED 95 90 95
TURNING SPEED 25 20 30
ACCELERATION - FWD 30 25 25
ACCELERATION - REV 30 20 25
TURN ACCELERATION 30 20 25
TURN DECELERATION 35 25 30
BRAKING FORWARD 50 50 50
BRAKING REVERSE 55 45 55
REVERSE SPEED 40 30 40
TREMOR DAMPENING 40 40 40
TORQUE 14448144
DEFAULT SETTINGS FOR NX-B
FUNCTION PROGRAM 1 PROGRAM 2 PROGRAM 3
ATM 2-POLE RWD 2-POLE CWD 2-POLE
FORWARD SPEED 95 95 100
TURNING SPEED 50 25 30
ACCELERATION - FWD 30 30 25
ACCELERATION - REV 30 30 25
TURN ACCELERATION 80 30 25
TURN DECELERATION 75 35 30
BRAKING FORWARD 85 50 50
BRAKING REVERSE 55 55 55
REVERSE SPEED 40 40 40
TREMOR DAMPENING 40 40 40
TORQUE 144 144 144
