Invacare Storm Arrow - Page 45

45
PROCEDURE 9 BATTERIES
STEPS 3 AND 4
Battery
Box Top
(Under Side
shown)
NEGATIVE (-)
BLACK Battery
Cable
Front
Battery
Rear
Battery
STEPS 5 AND 6
Battery
Box Top
Front
Battery
Battery
Box Bottom
FRONT
POSITIVE (+)
RED Battery
Cable
Fuse
Block
POSITIVE (+) RED Battery Cable
Battery Box Bottom
Rear
Battery
NEGATIVE (-)
Battery
Terminal/Post
POSITIVE (+)
Battery
Terminal/Post
NOTE: Battery box top cut away for clarification pur-
poses only.
FIGURE 3 - CONNECTING BATTERY CABLES - SINGLE 22NF BATTERY BOX
STEP 2
Single
Battery
Box
Bottom
WHITE Bat-
tery Cable
(Jumper)
Front
Battery
Rear
Battery
FRONT
REAR
N
P
DETAIL “A”
Terminal Cap
Terminal End
B
A
T
T
E
R
I
E
S
