Invacare Storm Arrow - SPECIFICATIONS

6
S
P
E
C
I
F
I
C
A
T
I
O
N
S
SPECIFICATIONS
SPECIFICATIONS
* in 1-inch increments
** Storm Torque/Torque SP model wheelchairs are available in rear wheel drive ONLY. Gearless Brushless Motor Option is
available on Storm Torque ONLY.
✪ With MKIV RII Controller. ● With MKIV Rx or A Controller. u Non-Recliners ONLY.
v Arrow specifications refer to RWD, MWD and FWD wheelchairs except where specified.
vARROW ** TORQUE **TORQUE SP X JUNIOR
Seat Width Range:
250 lbs Rating
✪ 16 to 20-in. *12 to 16-in.
MWD/RWD
300 lbs. Rating *16 to 22-in. 16 and 18-in.
● 16 to 20-in *16 to 22-in.
MWD/RWD FWD
400 lbs. Rating *19 to 24-in. *16 to 24-in.
Seat Depth Range: *16 to 22-in. 16 and 18-in. *16 to 18-in. *16 to 22-in. *12 to 15-in. w/CJ Back
Expandable to - *16 to 17-in.
Back Height Range: *16 to 24-in. 16, 18, 20,22-in. *16 to 22-in. *16 to 24-in. *12 to 18-in.
Seat-to-Floor
(approximate) MWD/RWD FWD Storm Base X Base
Standard: 17-1/2-in. 18-1/4-in. 17-1/2-in. 17-1/2-in. 17-1/2-in. 17-1/2-in. 17-1/2-in.
Optional: 19-3/4-in. 20-1/2-in. 19-3/4-in. 19-3/4-in. 19-3/4-in. 19-3/4-in. 19-3/4-in.
21-in. 21-3/4-in. N/A N/A 21-in.
Overall Width
of Base: 24-5/8-in. 25-1/4-in. 24-5/8-in. 24-5/8-in. 24-5/8-in.
(w/o joystick)
Overall Height MWD/RWD FWD Storm Base X Base
Standard: 34-1/4-in. 35-1/2-in 34-1/4-in. 34-1/4-in. 34-1/4-in. 34-1/4-in. 34-1/4-in.
Minimum: 34-1/4-in. 35-1/2-in N/A N/A 34-1/4-in. 32-1/4-in. 32-1/4-in.
Maximum: 44-1/4-in. 45-1/2-in N/A N/A 44-1/4-in. 40-1/2-in. 40-1/2-in.
Recliner - (Std.)
Low Seat Frame: 51-1/2-in. 52-3/4-in. N/A N/A 51-1/2-in. N/A
Med. Seat Frame: 53-3/4-in. 55-in. N/A N/A 53-1/4-in. N/A
High Seat Frame: 55-1/2 in. 58-1/2-in. N/A N/A 55-1/2-in. N/A
Overall Length
(without front
riggings) MWD/RWD FWD
Standard: 32-1/4-in. 35-1/4-in 32-1/4-in. 32-1/4-in. 32-1/4-in. 32-1/4-in.
Long Frame: 35-1/4-in. N/A N/A N/A 35-1/4-in. 35-1/4-in.
Weight
Standard Motor MWD/RWD FWD Storm Base X Base
W/O Batteries: 146 lbs. 199 lbs. 149 lbs. 149 lbs. 149 lbs. 146 lbs. 149 lbs.
W/Batteries:
Standard 248 lbs. 310 lbs. 224 lbs. 224 lbs. 224 lbs. 246 lbs. 224 lbs.
Optional N/A N/A 249 lbs. N/A 249 lbs. N/A 249 lbs.
Shipping (approx.): 176 lbs. 229 lbs. 176 lbs. 176 lbs. 176 lbs. 176 lbs. 176 lbs.
Gearless/Brushless
Motor
W/O Batteries: 166 lbs. N/A 169 lbs. N/A 169 lbs. 166 lbs. 169 lbs.
W/ Batteries:
Standard 243 lbs. N/A 243 lbs. N/A 243 lbs. 266 lbs. 243 lbs.
Optional 268 lbs. N/A 268 lbs. N/A 268 lbs. N/A 268 lbs.
Shipping (approx.): 196 lbs. N/A 196 lbs. N/A 196 lbs. 196 lbs. 196 lbs.
Drive Axle: *◆Adjustable (MWD/RWD only) *◆Adjustable *◆Adjustable *◆Adjustable *Adjustable
Drive Wheels/Tires:
(Foam Filled or
Pneumatic)
Standard: 14 X 3-in. 14 X 3-in. 14 X 3-in. 14 X 3-in. 14 X 3-in. 14 X 3-in.
Optional: 14 X 4-in. 14 X 4-in. 14 X 4-in. 14 X 4-in. 14 X 4-in. 14 X 4-in.
PHYSICAL
DIMENSIONS
