82
Battery Box
Sub-frame
REAR OF
CHAIR
FRONT OF
CHAIR
Spacer
Mounting Screw
(LOOSEN)
Retainer Clip
(Closed End)
GROUP 24 BATTERIES GROUP 22 BATTERIES
Mounting
Screw
Shock
Mounting
Screw
Locknut
Suspension
Arm
FIGURE 5 - SHOCK REPLACEMENT
Top of
Shock
Battery Box
Retainer
Bar
TOP OF SHOCK
BOTTOM OF SHOCK
GROUP 22 AND GROUP 24 BATTERIES
NOTE: Suspension arm for conventional motor shown.
Shock removes in the same manner for gearless/
brushless motor.
NOTE: Suspension arm shown is for conventional motors. Shock removes in the same manner for gearless/
brushless motor.
Shock
Suspension
Arm
RWD WHEELCHAIRSPROCEDURE 16
