Matrix Mono
Inventor Matrix Mono Engineering Data Book
Engin
eerin
g
Data
Matrix Mono
18
Matrix Mono Engineering Data Book
1 Specificaons
Outdoor unit model name ATM(H)08S(3) ATM(H)10S(3)
Power supply V/Ph/Hz 220-240/1/50
Heang A7W35
Capacity kW 4.20 6.35 8.40 10.0
Rated input kW 0.82 1.28 1.63 2.02
COP 5.10 4.95 5.15 4.95
Heang A7W45
Capacity kW 4.30 6.30 8.10 10.0
Rated input kW 1.13 1.70 2.10 2.67
COP 3.80 3.70 3.85 3.75
Heang A7W55
Capacity kW 4.40 6.00 7.50 9.50
Rated input kW 1.49 2.03 2.36 3.06
COP 2.95 2.95 3.18 3.10
Heang A-7W35
Capacity kW 4.70 6.00 7.00 8.00
Rated input kW 1.52 2.00 2.19 2.62
COP 3.10 3.00 3.20 3.05
Heang A-7W55
Capacity kW 4.00 5.15 6.15 6.85
Rated input kW 2.05 2.58 3.00 3.43
COP 1.95 2.00 2.05 2.00
Cooling A35W18
Capacity kW 4.50 6.50 8.30 9.90
Rated input kW 0.82 1.35 1.64 2.18
EER 5.50 4.80 5.05 4.55
Cooling A35W7
Capacity kW 4.70 7.00 7.45 8.20
Rated input kW 1.36 2.33 2.22 2.52
EER 3.45 3.00 3.35 3.25
Seasonal space heang
energy efficiency class
Water outlet at 35
C A+++
Water outlet at 55 C A++
SCOP
Warmer climate
35
C
6.46 6.57 6.99 7.09
55 C
4.15 4.21 4.51 4.62
Average climate
35
C
4.85 4.95 5.22 5.20
55 C
3.31 3.52 3.37 3.47
Colder climate
35 C
4.06 4.21 4.33 4.32
55 C
2.63 2.85 2.88 2.99
Sound power Level
2
dB 55 58 59 60
Rated water flow m
3
/h 0.72 1.09 1.44 1.72
Water flow range m
3
/h 0.4~0.9 0.4~1.25 0.4~1.65 0.4~2.1
Internal water volume L 3.2 3.2 3.2 3.2
Compressor Type Twin rotary
Outdoor fan Motor type / Number of fans DC fan / 1 DC fan / 1
Air side heat exchanger Finned tube
Refrigerant R32 1.4kg
Unit dimension (W×H×D) mm 1295×792×429 1385×945×526
Packing dimension (W×H×D) mm 1375×945×475 1465×1120×560
Net/Gross weight kg 98/121 121/148
Outdoor air
temperature range
Cooling
C -5
〜
43
Heating C -25
〜
35
ATM(H)04S(3)
ATM(H)06S(3)
