Matrix Mono
Inventor Matrix Mono Engineering Data Book
Matrix Mono
6
2 Unit Capacies
Table 1-2.1: Matrix Mono unit capacity range and unit appearances
Capacity 4kW 6kW 8kW 10kW 12kW 14kW 16kW
Model
1
ATM(H)04S(3) ATM(H)06S(3) ATM(H)08S(3) ATM(H)10S(3)
ATM(H)12S(3)/T(9) ATM(H)14S(3)/T(9) ATM(H)16S(3)/T(9)
Appearance
Notes:
1. The presence or omission of the leers S or T in the model names indicates the unit’s power supply:
T: 3
-phase, 380-415V, 50Hz; S: 1-phase, 220-240V, 50Hz.
3 Nomenclature
08
AT
M H S 33
3kW El
ectric Heater (choices: empty, 3, 9)
S=Single phase
T=Triple phase
8kW (choices: 04,06,08,10,12,14,16,)
With Electric Heater pre-installed
(choices: H or nothing)
M: Monoblock Type (S: Split-Type)
Heat pump
