Matrix Mono
Inventor Matrix Mono Engineering Data Book
Engin
eerin
g
Data
Matrix Mono
20
Matrix Mono Engineering Data Book
Outdoor unit model name ATM(H)12S(3) ATM(H)14S(3) ATM(H)16S(3)
Power supply V/Ph/Hz 220-240/1/50
Heang A7W35
Capacity kW 12.1 14.5 15.9
Rated input kW 2.44 3.15 3.53
COP 4.95 4.60 4.50
Heang A7W45
Capacity kW 12.3 14.1 16.0
Rated input kW 3.32 3.92 4.57
COP 3.70 3.60 3.50
Heang A7W55
Capacity kW 11.9 13.8 16.0
Rated input kW 3.90 4.68 5.61
COP 3.05 2.95 2.85
Heang A-7W35
Capacity kW 10.00 12.00 13.10
Rated input kW 3.33 4.21 4.85
COP 3.00 2.85 2.70
Heang A-7W55
Capacity kW 9.80 11.00 12.50
Rated input kW 4.78 5.37 6.25
COP 2.05 2.05 2.00
Cooling A35W18
Capacity kW 12.00 13.50 14.90
Rated input kW 3.04 3.75 4.38
EER 3.95 3.60 3.40
Cooling A35W7
Capacity kW 11.5 12.4 14.0
Rated input kW 4.18 4.96 5.60
EER 2.75 2.50 2.50
Seasonal space heang energy
efficiency class
Water outlet at 35⁰C A+++
Water outlet at 55⁰C A++
SCOP
Warmer climate
35
C
6.48 6.58 6.29
55 C
4.43 4.49 4.48
Average climate
35
C
4.81 4.72 4.62
55 C
3.45 3.47 3.41
Colder climate
35 C
4.08 4.07 4.02
55 C
3.02 3.05 3.12
Sound power Level
2
dB
65 65 68
Rated water flow m
3
/h
2.08 2.49 2.73
Water flow range m
3
/h 0.7~2.5 0.7~2.75 0.7~3.0
Internal water volume L 2 2 2
Compressor Type Twin rotary
Outdoor fan
Motor type DC fan
Number of fans 1
Air side heat exchanger Finned tube
Refrigerant R32 1.75kg
Unit dimension (W×H×D) mm 1385×945×526
Packing dimension (W×H×D) mm 1465×1120×560
Net/Gross weight kg 144/170
Outdoor air temperature range
Cooling ⁰C
-5
〜
43
Heang ⁰C
-25
〜
35
DHW ⁰C
-25
〜
43
