9. Power Cord Connecon of group control system
Use a dedicated power supply for the indoor unit that is different from the power supply for the outdoor unit.
Use the same power supply, circuit breaker and leakage protecve device for the indoor units connected to the same
outdoor unit.
+
Power cord
Insulation tube
Circular wiring
terminal
: Copper wi
re
Proper power wiring connections
Power Supply
Circuit Breaker
Manual swtich
Wire Distribution Box
......
