Table 2-5.6: Heang capacity for ATM14(H)S(3)(T)(9)
Maximum
DB
LWT
25 30 35 40 45 50 55 60 65
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 6.60 3.09 2.14 6.76 3.20 2.11 5.43 3.18 1.71 4.89 3.35 1.46 4.47 3.47 1.29
-20 8.26 3.22 2.57 8.30 3.30 2.52 7.79 3.58 2.18 6.89 3.65 1.89 6.25 3.61 1.73 5.42 3.61 1.50 5.14 3.87 1.33
-15 9.61 3.40 2.82 9.57 3.65 2.62 9.57 3.94 2.43 8.57 3.95 2.17 7.63 4.12 1.85 7.01 4.32 1.62 6.46 4.58 1.41 6.01 5.05 1.19
-10
11.9 3.81 3.12 11.4 4.18 2.73 11.0 4.44 2.47 10.6 4.70 2.26 9.64 4.73 2.04 9.07 5.01 1.81 8.72 5.21 1.67 6.73 5.30 1.27
-7
13.7 4.02 3.41 12.9 4.28 3.02 12.7 4.55 2.79 12.3 4.94 2.49 11.9 5.17 2.31 11.0 5.33 2.07 11.3 5.46 2.01 8.02 5.31 1.51
-5
13.9 3.78 3.68 13.2 3.87 3.41 12.5 4.16 2.99 12.6 4.61 2.73 12.1 4.99 2.42 11.2 5.24 2.13 11.1 5.32 2.09 8.25 5.06 1.63
0
14.3 3.40 4.21 13.7 3.54 3.87 12.4 3.82 3.26 13.0 4.32 3.01 12.7 4.85 2.62 11.9 4.99 2.38 11.8 5.19 2.27 9.34 5.48 1.70
5
15.4 2.93 5.25 14.9 3.30 4.51 14.3 3.63 3.94 14.3 3.95 3.61 14.3 4.59 3.11 13.8 4.98 2.77 13.8 5.18 2.66 11.7 5.38 2.17 9.76 5.33 1.83
7
16.3 2.81 5.80 15.6 3.15 4.94 15.5 3.37 4.59 15.6 3.86 4.04 15.7 4.35 3.60 15.0 4.81 3.11 14.5 4.92 2.95 13.2 5.20 2.54 10.4 4.95 2.10
10
15.5 2.28 6.81 15.5 2.89 5.36 14.9 3.10 4.79 15.3 3.60 4.24 15.0 4.08 3.67 15.3 4.62 3.31 14.2 4.60 3.08 13.2 4.91 2.69 11.2 4.98 2.26
15 15.3 2.01 7.62 15.2 2.62 5.79 15.2 2.94 5.16 15.8 3.56 4.45 15.5 3.98 3.89 15.3 4.37 3.51 13.0 4.02 3.24 12.7 4.48 2.84 11.9 4.97 2.41
20 14.9 1.78 8.35 14.8 2.20 6.74 14.6 2.59 5.65 15.2 3.04 5.01 15.1 3.42 4.42 15.0 3.84 3.90 12.7 3.62 3.52 11.0 3.77 2.92
25 14.9 1.64 9.08 14.7 1.92 7.69 14.6 2.38 6.15 14.9 2.68 5.57 14.7 2.98 4.95 14.7 3.43 4.30 12.5 3.28 3.80 10.2 3.40 2.99
30 15.3 1.55 9.82 14.8 1.80 8.21 14.9 2.10 7.09 15.1 2.42 6.22 15.0 2.80 5.36 14.6 3.14 4.65 12.8 2.93 4.37 10.3 3.40 3.04
35 16.0 1.45 11.1 15.4 1.70 9.04 15.0 1.87 8.02 15.5 2.26 6.86 15.3 2.65 5.77 14.8 2.95 5.00 13.0 2.77 4.69
40 16.2 1.40 11.6 16.4 1.59 10.3 16.2 1.89 8.57 16.0 2.20 7.26 15.8 2.59 6.08 15.0 2.78 5.38
43 16.5 1.36 12.2 16.7 1.54 10.8 16.5 1.88 8.81 16.3 2.12 7.69 16.1 2.56 6.27 15.2 2.73 5.54
Normal
DB
LWT
25 30 35 40 45 50 55 60 65
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 5.65 2.48 2.27 5.75 2.55 2.25 4.57 2.55 1.79 4.19 2.76 1.51 3.88 2.97 1.30
-20 7.27 2.63 2.77 7.27 2.67 2.72 6.75 2.92 2.32 6.07 3.06 1.99 5.48 3.08 1.78 4.77 3.08 1.55 4.69 3.52 1.33
-15 8.03 2.63 3.06 7.94 2.79 2.85 7.86 3.03 2.60 7.16 3.12 2.29 6.24 3.26 1.91 5.76 3.42 1.68 5.41 3.81 1.42 5.09 4.31 1.18
-10
9.80 2.96 3.31 9.36 3.22 2.91 8.89 3.43 2.59 8.76 3.74 2.34 8.07 3.85 2.09 7.63 4.08 1.87 7.34 4.26 1.72 5.73 4.44 1.29
-7
12.7 3.56 3.56 12.2 3.94 3.09 12.0 4.21 2.85 11.9 4.46 2.66 11.8 5.02 2.35 10.9 5.15 2.11 11.0 5.37 2.05 7.41 4.77 1.55
-5
11.6 2.89 4.00 10.8 2.96 3.66 9.98 3.11 3.21 10.2 3.45 2.95 9.68 3.77 2.57 8.78 3.96 2.22 8.83 4.05 2.18 6.77 4.04 1.68
0
11.4 2.48 4.59 10.8 2.58 4.17 9.52 2.72 3.50 10.1 3.08 3.27 9.74 3.48 2.79 8.78 3.62 2.42 8.78 3.70 2.38 7.18 4.08 1.76
5
12.4 2.15 5.78 11.9 2.42 4.90 11.1 2.60 4.27 11.2 2.83 3.96 11.1 3.31 3.35 10.5 3.60 2.92 10.6 3.77 2.81 9.31 4.11 2.27 8.06 4.19 1.93
7
15.2 2.43 6.26 14.5 2.77 5.24 14.5 3.15 4.60 14.6 3.52 4.15 14.1 3.92 3.60 14.0 4.40 3.18 13.8 4.68 2.95 12.3 4.73 2.61 9.71 4.50 2.16
10
12.3 1.63 7.53 12.1 2.07 5.85 11.3 2.17 5.22 11.8 2.52 4.67 11.4 2.87 3.97 11.4 3.30 3.46 10.6 3.31 3.21 10.3 3.71 2.78 9.11 3.88 2.35
15 12.2 1.43 8.50 11.9 1.87 6.37 11.6 2.05 5.67 12.3 2.49 4.94 11.9 2.80 4.25 11.5 3.11 3.70 9.84 2.88 3.41 10.0 3.38 2.96 9.68 3.78 2.56
20 11.7 1.25 9.40 11.5 1.54 7.49 11.1 1.77 6.27 11.7 2.08 5.62 11.5 2.35 4.87 11.1 2.68 4.16 9.53 2.55 3.74 8.54 2.78 3.07
25 11.8 1.15 10.2 11.6 1.35 8.55 11.1 1.63 6.82 11.5 1.66 6.93 11.3 2.06 5.46 11.0 2.41 4.58 9.40 2.32 4.04 7.95 2.53 3.14
30 12.2 1.11 11.0 11.7 1.29 9.07 11.4 1.46 7.81 11.7 1.54 7.64 11.6 2.05 5.63 11.0 2.24 4.92 9.74 2.13 4.56 8.17 2.58 3.17
35 13.0 1.06 12.3 12.4 1.25 9.93 11.8 1.36 8.63 12.3 1.67 7.39 12.0 1.96 6.10 11.4 2.13 5.33 10.1 2.05 4.93
40 13.5 1.04 13.0 13.6 1.19 11.4 13.1 1.41 9.28 13.0 1.65 7.88 12.7 1.96 6.48 11.8 2.04 5.78
43 14.1 1.02 13.8 14.1 1.17 12.1 13.6 1.41 9.61 13.5 1.61 8.40 13.2 1.96 6.73 12.2 2.04 5.99
Minimum
DB
LWT
25 25 25 25 25 25 25 25 25
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 3.76 1.62 2.33 4.02 1.74 2.30 3.54 1.94 1.82 3.33 2.17 1.54 3.00 2.29 1.31
-20 4.58 1.63 2.80 4.77 1.73 2.76 4.40 1.87 2.35 4.02 1.99 2.02 4.06 2.31 1.76 3.79 2.47 1.54 3.65 2.76 1.32
-15 5.24 1.68 3.13 5.40 1.85 2.91 5.31 2.00 2.66 4.91 2.09 2.35 4.88 2.56 1.91 4.84 2.87 1.68 4.52 3.17 1.43 4.33 3.65 1.19
-10 5.05 1.47 3.44 5.08 1.68 3.02 4.76 1.79 2.66 4.80 1.99 2.41 5.01 2.35 2.13 5.17 2.71 1.90 5.40 3.08 1.76 4.51 3.43 1.32
-7 5.14 1.34 3.84 4.55 1.35 3.36 4.57 1.48 3.10 4.96 1.77 2.80 6.21 2.46 2.52 5.96 2.71 2.20 6.25 2.90 2.15 5.22 3.26 1.60
-5 5.35 1.28 4.17 4.78 1.25 3.81 4.61 1.38 3.34 5.19 1.69 3.07 6.40 2.41 2.65 6.15 2.69 2.28 6.46 2.88 2.24 5.44 3.15 1.73
0 5.73 1.19 4.80 5.34 1.22 4.36 4.79 1.31 3.66 5.57 1.63 3.42 6.92 2.39 2.90 6.61 2.67 2.48 6.90 2.81 2.46 6.17 3.39 1.82
5 6.23 1.03 6.07 5.89 1.14 5.15 5.58 1.24 4.49 6.18 1.49 4.16 7.86 2.25 3.49 7.86 2.59 3.03 8.68 2.98 2.91 7.95 3.38 2.35 6.88 3.44 2.00
7 6.48 0.96 6.75 6.03 1.06 5.68 5.92 1.12 5.27 6.64 1.42 4.68 8.50 2.09 4.07 8.43 2.46 3.43 9.05 2.78 3.25 8.88 3.21 2.77 7.25 3.14 2.31
10 6.34 0.80 7.93 6.18 1.00 6.16 5.84 1.06 5.50 6.66 1.35 4.92 8.28 2.00 4.15 8.77 2.40 3.65 8.96 2.67 3.36 9.02 3.10 2.91 7.95 3.23 2.46
15 6.01 0.67 8.90 5.97 0.89 6.68 5.93 1.00 5.94 7.33 1.42 5.18 8.59 1.94 4.42 9.47 2.43 3.89 8.45 2.38 3.55 9.04 2.93 3.09 8.72 3.29 2.65
20 5.95 0.60 9.84 5.93 0.76 7.85 5.83 0.89 6.57 7.16 1.22 5.88 8.48 1.68 5.06 9.35 2.14 4.36 8.36 2.15 3.89 7.88 2.47 3.19
25 6.09 0.57 10.7 6.05 0.68 8.95 5.96 0.83 7.15 7.17 1.10 6.54 8.42 1.48 5.67 9.33 1.94 4.80 8.32 1.98 4.21 7.38 2.26 3.27
30 7.11 0.62 11.5 7.26 0.76 9.49 8.10 1.01 8.02 8.43 1.20 7.05 8.68 1.46 5.92 9.37 1.81 5.17 8.70 1.81 4.80 7.34 2.20 3.33
35 7.63 0.59 13.0 7.69 0.73 10.5 8.32 0.91 9.15 8.83 1.13 7.84 8.98 1.40 6.42 9.63 1.72 5.61 8.97 1.73 5.19
40 7.89 0.57 13.8 8.37 0.69 12.1 9.16 0.93 9.84 9.10 1.09 8.35 9.29 1.36 6.82 9.89 1.63 6.08
43 8.30 0.57 14.6 8.79 0.69 12.8 9.59 0.94 10.2 9.53 1.07 8.90 9.24 1.31 7.08 10.3 1.63 6.30
LWT: Leaving water temperature (°C )
DB: Dry-bulb temperature for Outdoor air temperature (°C )
HC: Total heang capacity (kW)
PI: Power input (kW)
