Page 6
Accessories
2
The air conditioning system comes with the following accessories. Use all of the installation parts
and accessories to install the air conditioner. Improper installation may result in water leakage,
electrical shock and re, or equipment failure.
Name Shape Quantity
Indoor unit
installation
Safety lock (some models)
1
Self-tapping screw 3.9×25
(some models)
2
Flat washers (some models)
2
Bushing-sleeve cover
(some models)
1
Refrigeration
Fittings
Soundproof/insulation
sheath (some models)
2
Drainpipe
Fittings
Drain hose (some models)
1
Band (some models)
2
Drain joint (some models)
1
Seal ring (some models)
1
Installation
Accessory (some
models)
Connection cables
1
Putty
1
Rodent-proof mesh
Self-tapping screw ST3.9×12
1
Remote
controller & Its
Frame (some
models)
1
1
2
1
1
1
1
1
2
Remote controller
Fixing screw for remote
controller holder ST2.9 x 10
Remote controller holder
Dry battery AAA
Owner’s manual
Installation manual
Refrigerant Pipe (optional)
Remote controller illustration
If there is any dierence between the above table and the Packing List, the Packing List should prevail.
Page 7
Installation Overview
3
1
2
3
4
5
MC MC
6
7
Install the indoor unit
(Page 7)
INSTALLATION ORDER
Install the outdoor unit
(Page 11)
Install the drainpipe
(Page 14)
Evacuate the refrigeration system
(Page 23)
Connect the wires
(Page 19)
Connect the refrigerant pipes
(Page 16)
Perform a test run
(Page 23)
To Next Page
