Invertek Optidrive P2 series User Manual

Optidrive ODP-2 User Guide Revision 2.10
www.invertekdrives.com
13
3
Mechanical Installation
3.4.2. IP55 Units
Drive
Size
A
B
C
D
E
F
G
H
I
Weight
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
kg
lb
4
450
17.72
428
16.85
433
17.05
8
0.31
252
9.92
171
6.73
110
4.33
4.25
0.17
7.5
0.30
11.5
25.4
5
540
21.26
515
20.28
520
20.47
8
0.31
270
10.63
235
9.25
175
6.89
4.25
0.17
7.5
0.30
23
50.7
6
865
34.06
830
32.68
840
33.07
10
0.39
330
12.99
330
12.99
200
7.87
5.5
0.22
11
0.43
55
121.2
7
1280
50.39
1245
49.02
1255
49.41
10
0.39
360
14.17
330
12.99
200
7.87
5.5
0.22
11
0.43
89
196.2
Mounting Bolts
Tightening Torques
Frame Size
Metric
UNF
Frame Size
Required Torque
4
M8
#8
Control Terminals
All
0.5 Nm
4.5 lb-in
5
M8
#8
Power Terminals
4
2 Nm
18 lb-in
6
M10
5/16
5
4 Nm
35.5 lb-in
7
M10
5/16
6
15 Nm
11 lb-ft
7
15 Nm
11 lb-ft
