Invertek Optidrive P2 series User Manual

Optidrive ODP-2 User Guide Revisions 2.10
14
www.invertekdrives.com
3
Mechanical Installation
3.4.3. IP66 Units
H
G
F
Note : Unit shown is a non-switched unit
Drive
Size
A
B
D
E
F
G
H
I
J
Weight
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
kg
lb
2
257
10.12
220
8.66
200
7.87
29
1.12
239
9.41
188
7.40
178
7.01
4.2
0.17
8.5
0.33
4.8
10.6
3
310
12.20
277
10.89
252
9.90
33
1.31
266
10.47
211
8.29
200
7.87
4.2
0.17
8.5
0.33
7.7
16.8
Mounting Bolts
Tightening Torques
Frame Size
Metric
UNF
Frame Size
Required Torque
2
M4
#8
Control Terminals
All
0.5 Nm
4.5 lb-in
3
M4
#8
Power Terminals
2 & 3
1 Nm
9 lb-in
D B A
I
J
