INVT CHV100 Series User Manual

List of Function Parameters
112
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P2.01
Motor rated
frequency
0.01Hz~P0.07 50.00Hz ◎
MOTOR
RATE FREQ
P2.02 Motor rated speed 0~36000rpm
1460
rpm
◎
MOTOR
RATE SPEED
P2.03 Motor rated voltage 0~3000V
Depend
on model
◎
MOTOR
RATE VOLT
P2.04 Motor rated current 0.1~2000.0A
Depend
on model
◎
MOTOR
RATE CURR
P2.05 Motor rated power 1.5~900.0kW
Depend
on model ◎
MOTOR
RATE
POWER
P2.06
Motor stator
resistance
0.001~65.535Ω
Depend
on model
○
STATOR
RESISTOR
P2.07
Motor rotor
resistance
0.001~65.535Ω
Depend
on model
○
ROTOR
RESISTOR
P2.08
Motor leakage
inductance
0.1~6553.5mH
Depend
on model
○
LEAK
INDUCTOR
P2.09
Motor mutual
inductance
0.1~6553.5mH
Depend
on model
○
MUTUAL
INDUCTOR
P2.10
Current without
load
0.01~655.35A
Depend
on model
○
NO LOAD
CURR
P3 Group: Vector Control
P3.00
ASR proportional
gain K
p
1
0~100 20 ○ ASR Kp1
P3.01
ASR integral time
K
i
1
0.01~10.00s 0.50s ○ ASR Ki1
P3.02
ASR switching
point 1
0.00Hz~P3.05 5.00Hz ○
ASR
SWITCHPOIN
T1
P3.03
ASR proportional
gain K
p
2
0~100 25 ○ ASR Kp2
P3.04
ASR integral time
K
i
2
0.01~10.00s 1.00s ○ ASR Ki2
