INVT CHV100 Series User Manual

Wiring
23
4.4.3 Specification of braking unit and braking resistor
Braking unit
Braking resistor
(100% braking torque) Model No.
Order No. Quantity Specification Quantity
3AC 220V ±15%
CHV100-1R5G-2
138Ω/150W 1
CHV100-2R2G-2
91Ω/220W 1
CHV100-004G-2
52Ω/400W 1
CHV100-5R5G-2
37.5Ω/550W 1
CHV100-7R5G-2
Build-in 1
27.5Ω/750W 1
CHV100-011G-2
19Ω/1100W 1
CHV100-015G-2
13.6Ω/1500W 1
CHV100-018G-2
12Ω/1800W 1
CHV100-022G-2
9Ω/2200W 1
CHV100-030G-2
DBU-055-2 1
6.8Ω/3000W 1
CHV100-037G-2
11Ω/2000W 2
CHV100-045G-2
DBU-055-2 2
9Ω/2400W 2
3AC 380V ±15%
CHV100-1R5G-4 400Ω/260W 1
CHV100-2R2G-4
CHV100-004G-4
150Ω/390W 1
CHV100-5R5G-4 100Ω/520W 1
CHV100-7R5G-4
CHV100-011G-4
50Ω/1040W 1
CHV100-015G-4
Build- in 1
40Ω/1560W 1
CHV100-018G-4
CHV100-022G-4
CHV100-030G-4
20Ω/6000W 1
CHV100-037G-4
CHV100-045G-4
CHV100-055G-4
DBU-055-4 1
13.6Ω/9600W 1
CHV100-075G-4
CHV100-090G-4
DBU-055-4 2
13.6Ω/9600W 2
