CHV180 series frequency inverter special for elevator Appendix D
.139.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
17: Contactor
feedback signal
18: Brake feedback
signal
19: Inverter enable
20:Forcing
deceleration stop
21~40: reversed
FUNCTION
P5.10 S9 Terminal function
0 ◎
S9
FUNCTION
P5.11 S10 Terminal function
0 ◎
S10
FUNCTION
P5.12
Switch signal filter
times
1~10 5 ○
Sx FILTER
TIMES
P5.13 AI1 lower limit 0.00V~P5.15 0.00V ○
AI1 LOW
LIMIT
P5.14
AI1 lower limit
corresponding setting
-100.0%~100.0% 0.0% ○
AI1 LOW
SETTING
P5.15 AI1 upper limit P5.13~10.00V 10.00V ○
AI1 UP LIMIT
P5.16
AI1 upper limit
corresponding setting
-100.0%~100.0% 100.0%
○
AI1 UP
SETTING
P5.17 AI1 filter time constant
0.00s~10.00s 0.10s ○
AI1 FILTER
TIME
P5.18
AI2 lower limit 0.00V~P5.20 0.00V ○
AI2 LOW
LIMIT
P5.19 AI2 lower limit
corresponding setting
-100.0%~100.0% 0.0% ○
AI2 LOW
SETTING
P5.20 AI2 upper limit P5.18~10.00V 5.00V ○
AI2 UP LIMIT
P5.21
AI2 upper limit
corresponding setting
-100.0%~100.0% 100.0%
○
AI2 UP
SETTING
P5.22 AI2 filter time constant
0.00s~10.00s 0.10s ○
AI2 FILTER
TIME
P6 Group: Output terminals
P6.00
HDO output
selection
0: High-speed pulse
output
1: ON-OFF output
0 ◎
HDO
SELECTION
