CHV180 series frequency inverter special for elevator General
.6.
Model No.
Rated power
(kW)
Rated input
current (A)
Rated output
current (A)
Size
CHV180-004G-4
3.7 10.0 9.0 C
CHV180-5R5G-4
5.5 15.0 13.0 C
CHV180-7R5G-4
7.5 20.0 17.0 D
CHV180-011G-4
11.0 26.0 25.0 D
CHV180-015G-4
15.0 35.0 32.0 D
CHV180-018G-4
18.5 38.0 37.0 E
CHV180-022G-4
22.0 46.0 45.0 E
CHV180-030G-4
30.0 62.0 60.0 E
1.4 Parts description
Figure 1.3 Parts of inverter (15kW and below)
