INVT CHV180-7R5G-4

CHV180 series frequency inverter special for elevator Appendix D
.141.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
LIMIT
P6.15
AO2 lower limit
corresponding output
0.00V ~10.00V 0.00V ○
AO2 LOW
OUTPUT
P6.16 AO2 upper limit P6.14~100.0% 100.0%
○
AO1 UP LIMIT
P6.17
AO2 upper limit
corresponding output
0.00V ~10.00V 10.00V ○
AO2 UP
OUTPUT
P6.18 AO3 lower limit 0.0%~P6.20 0.0% ○
HDO LOW
LIMIT
P6.19
HDO lower limit
corresponding output
0.0 ~ 50.0kHz 0.0kHz ○
HDO LOW
OUTPUT
P6.20 AO3 upper limit P6.18~100.0% 100.0%
○
HDO UP
LIMIT
P6.21
HDO upper limit
corresponding output
0.0 ~ 50.0kHz 50.0kHz
○
HDO UP
OUTPUT
P6.22
FDT level detection
value
0.00~P0.07 50.00Hz
○
FDT LEVEL
P6.23
FDT lag detection
value
0.0~100.0 5.0% ○
FDT LAG
P6.24
Frequency arrival
detecting range
0.00~100.0% 0.0% ○
FREQ
ARRIVE
DETECT
P6.25~
P6.26
Reserved 0~65535 0 ◎
RESERVE
P7 Group: Display interface
P7.00 User password 0~65535 0 ○
USER
PASSWORD
P7.01
LCD language
selection
0: Chinese
1: English
0 ○
LANGUAGE
SELECT
P7.02 Parameter copy
0: Invalid
1: Upload parameters
to LCD
2: Download
0 ◎
PARA COPY
