Goodrive20 inverters Function Parameters
43
Function
code
Name Detailed instruction of parameters
Default
value
Modify
rotation
upper-limit
frequency in
torque control
7~9: Reserved
Note: setting method 1~9, 100% corresponds to the
maximum frequency
P03.16
Torque control
forward
rotation
upper-limit
frequency
keypad defined
value
This function is used to set the upper limit of the frequency.
P03.16 sets the value of P03.14; P03.17 sets the value of
P03.15.
Setting range:0.00 Hz~P00.03 (the Max. output frequency)
50.00 Hz
○
P03.17
Torque control
reverse
rotation
upper-limit
frequency
keypad defined
value
50.00 Hz
○
P03.18
Upper-limit
setting of
electromot
ion
torque
This function code is used to select the electromotion and
braking torque upper-limit setting source selection.
0: Keypad setting upper-limit frequency (P03.20 sets
P03.18 and P03.21 sets P03.19)
1: Analog AI1 setting upper-limit torque
2: Analog AI2 setting upper-limit torque
3: Analog AI3 setting upper-limit torque
4: Pulse frequency HDI setting upper-limit torque
5: MODBUS communication setting upper-limit torque
6~8: Reserved
Note: Setting mode 1~8,100% corresponds to three times
of the motor current.
0 ○
P03.19
Upper-limit
setting of
braking torque
0 ○
P03.20
Electromotion
torque
upper-limit
keypad setting
The function code is used to set the limit of the torque.
Setting range:0.0~300.0%(motor rated current)
180.0%
○
P03.21
Braking
torque
upper-limit
keypad setting
180.0%
○
P03.22
Weakening
coefficient in
The usage of motor in weakening control.
Function code P03.22 and P03.23 are effective at constant
0.3 ○
