INVT GD20-0R7G-4-EU User Manual

Goodrive20-EU series VFD Function parameters
49
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
10.000s
Setting range of P03.02: 0.00Hz – P00.05
Setting range of P03.05: P03.02 – P00.03
P03.06
Speed loop
output filter
0 – 8 (corresponds to 0 – 2
8
/10ms)
0
○
P03.07
Compensation
coefficient of
vector control
electromotion
slip
Slip compensation coefficient is used to adjust
the slip frequency of the vector control and
improve the speed control accuracy of the
system. Adjusting the parameter properly can
control the speed steady-state error.
Setting range: 50% – 200%
100%
○
P03.08
Compensation
coefficient of
vector control
brake slip
100%
○
P03.09
Current loop
proportional
coefficient P
Note:
These two parameters adjust the PI adjustment
parameter of the current loop which affects the
dynamic response speed and control accuracy
directly. Generally, users do not need to change
the default value;
Only apply to the vector control mode without PG
0 (P00.00=0).
Setting range: 0 – 65535
1000
○
P03.10
Current loop
integral
coefficient I
1000
○
P03.11
Torque setting
mode selection
This parameter is used to enable the torque
control mode, and set the torque setting means.
0: Torque control is invalid
1: Set via keypad（P3.12）
2: Set via AI1 (100% relative to three times of
motor current)
3: Set via AI2 (100% relative to three times of
motor) (same as above)
4: Set via AI3 (100% relative to three times of
motor) (same as above)
5: Set via pulse frequency HDI (same as above)
6: Multi-step torque setting (same as above)
7: Set via MODBUS communication
8 – 10: Reserved
0
○
