Goodrive20-EU series VFD Function parameters
50
Detailed instruction of parameters
Note: Setting mode 2 – 7, 100% corresponds to
3 times of the motor rated current
Setting range: -300.0% – 300.0% (motor rated
current)
Setting source
of upper-limit
frequency of
forward
rotation in
torque control
0: Set via keypad (P03.16 sets P03.14, P03.17
sets P03.15)
1: Set via AI1 (100% corresponds to max.
frequency)
2: Set via AI2 (same as above)
3: Set via AI3 (same as above)
4: Set via pulse frequency HDI (same as above)
5: Set via multi-step (same as above)
6: Set via MODBUS communication (same as
above)
7 – 9: Reserved
Note: setting method 1 – 9, 100% corresponds to
the maximum frequency
Setting source
of upper-limit
frequency of
reverse
rotation in
torque control
Torque control
forward
rotation
upper-limit
frequency
keypad limit
value
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz – P00.03 (the max. output
frequency)
Torque control
reverse
rotation
upper-limit
frequency
keypad limit
value
Upper-limit
setting of
electromotion
torque
This function code is used to select the
electromotion and braking torque upper-limit
setting source selection.
0: Set via keypad (P03.20 sets P03.18 and
