INVT GD20-0R7G-4-EU User Manual

Goodrive20-EU series VFD Function parameters
58
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
34: DC brake
35: Reserved
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
39: Pre-magnetized command
40: Clear the power consumption
41: Keep the power consumption
42: Emergency stop
43 – 60: Reserved
61: PID pole switching
62 – 63: Reserved
When terminals are used for acceleration/
deceleration time selection, the four groups of
acceleration/deceleration time are selected
based on the states of Acceleration/deceleration
time selection terminal 1 (21) and
Acceleration/deceleration time selection terminal
2 (22).
Terminal
1 (21)
Terminal
2 (22)
Acceleration or
deceleration time
Parameters
OFF
OFF
Acceleration/
deceleration time 1
P00.11/
P00.12
ON
OFF
Acceleration/
deceleration time 2
P08.00/
P08.01
OFF
ON
Acceleration/
deceleration time 3
P08.02/
P08.03
ON
ON
Acceleration/
deceleration time 4
P08.04/
P08.05
P05.10
Input terminal
polarity
selection
The function code is used to set the polarity of
the input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT8
BIT7
BIT6
BIT5
BIT4
HDI
S8
S7
S6
S5
BIT3
BIT2
BIT1
BIT0
S4
S3
S2
S1
Setting range: 0x000 – 0x1FF
0x000
○
