INVT GD20-0R7G-4-EU User Manual

Goodrive20-EU series VFD Function parameters
74
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P08.04
Acceleration
time 4
Terminal
1 (21)
Terminal
2 (22)
Acceleration or
deceleration time
Corresponding
parameters
OFF
OFF
Acceleration/
deceleration time 1
P00.11/
P00.12
ON
OFF
Acceleration/
deceleration time 2
P08.00/
P08.01
OFF
ON
Acceleration/
deceleration time 3
P08.02/
P08.03
ON
ON
Acceleration/
deceleration time 4
P08.04/
P08.05
Refer to P00.11 and P00.12 for detailed
definition.
The first group of acceleration/deceleration time
is the factory default one.
Setting range: 0.0 – 3600.0s
○
P08.05
Deceleration
time 4
○
P08.06
Jog running
frequency
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz – P00.03 (the max.
frequency)
5.00Hz
○
P08.07
Jogging
running
acceleration
time
The jogging acceleration time means the time
needed if the VFD runs from 0Hz to the max.
frequency.
The jogging deceleration time means the time
needed if the VFD goes from the max. frequency
(P00.03) to 0Hz.
Setting range: 0.0 – 3600.0s
Depend
on
model
○
P08.08
Jogging
running
deceleration
time
○
P08.09
Jumping
frequency 1
When the set frequency is in the range of
jumping frequency, the VFD will run at the edge
of the jumping frequency.
The VFD can avoid the mechanical resonance
point by setting the jumping frequency. The VFD
can set three jumping frequency. But this
function will be invalid if all jumping points are 0.
0.00Hz
○
P08.10
Jumping
frequency
range 1
0.00Hz
○
P08.11
Jumping
frequency 2
0.00Hz
○
P08.12
Jumping
frequency
range 2
0.00Hz
○
