INVT GD350-045G/055P-45-AS-B

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-160-
Function
code
Name
Description
Default
value
Modify
mind.
Password protection will be effective one minute
after exiting function code edit state, and it will
display "0.0.0.0.0" if users press PRG/ESC key
to enter function code edit state again, users
need to input the correct password.
Note: Restoring to default values will clear user
password, use this function with caution.
P07.01
Reserved
/
/
P07.02
Function of keys
Range: 0x00–0x27
Ones: Function selection of QUICK/JOG key
0: No function
1: Jogging
2: Reserved
3: Forward/reverse rotation switch-over
4: Clear UP/DOWN setting
5: Coast to stop
6: Switch over the running command reference
mode in sequence
7: Reserved
Tens: Reserved
0x01
◎
P07.03
Running
command
channel
switch-over
sequence of
QUICK key
When P07.02=6, set the switch-over sequence
of running command channel.
0: keypad control→terminal control→
communication control
1: keypad control←→terminal control
2: keypad control←→communication control
3: terminal control←→communication control
0
○
P07.04
Stop function
selection of
STOP/RST key
Validness selection of stop function of
STOP/RST.
For fault reset, STOP/RST is valid under any
situation.
0: valid only for panel control only
1: valid for both panel and terminal control
2: valid for both panel and communication
control
3: valid for all control modes
0
○
P07.05–
P07.07
Reserved
/
/
P07.08
Frequency
display
coefficient
0.01–10.00
Display frequency=running frequency× P07.08
1.00
○
P07.09
Speed display
coefficient
0.1–999.9%
Mechanical speed=120×display running
frequency×P07.09/number of motor pole pairs
100.0%
○
