Goodrive35 Series Closed-loop Vector Control VFD Product overview
11
3.5 Model code
The model code contains information on the VFD. The user can find the model code from the
nameplate on the the VFD or from the simplified nameplate.
GD35–5R5G–4–H1
① ②
③
④
Figure 3-5 Model code
Key
Sign
Instruction
Content
Abbreviation
①
Abbreviation
Goodrive35: Goodrive35 close-loop vector control VFDs
Rated power
②
Power + Load
5R5-5.5 kW
G—constant torque load
Voltage
degree
③
Voltage degree
4: AC 3PH 380 V (-15%)–440 V (+10%)
Rated voltage: 380 V
6: AC 3PH 520 V (-15%)–690 V (+10%)
Rated voltage: 660 V
Lot number
④
Lot number
C1: Support 24 V incremental encoder
D1: Support rotary transformer
Optional PG cards with functions of pulse and direction
pulse input reference
H1: Support 5 V/12 V incremental encoder, differential,
push-pull, and open collector signals;
Pulse + direction pulse input reference
H2: Support 5 V incremental encoder for high-speed
differential signal processing;
Pulse + direction pulse input reference (specific for
machine tools)
S1: Support sin/cos encoder, sin/cos (1 Vpp) eg
Heidenhain ERN1387; support quadrature pulse input
3.6 Rated values
3.6.1 Rated value of AC 3PH 380 V (-15%)–440 V (+10%)
Model
Output
power (kW)
Input current
(A)
Output
current (A)
Carrier
frequency (kHz)
GD35-1R5G-4-C1/D1/H1
1.5
5.0
3.7
1–15 (8)
GD35-2R2G-4-C1/D1/H1
2.2
5.8
5
1–15 (8)
GD35-004G-4-C1/D1/H1/H2/S1
4
13.5
9.5
1–15 (8)
GD35-5R5G-4-C1/D1/H1/H2/S1
5.5
19.5
14
1–15 (8)
GD35-7R5G-4-C1/D1/H1/H2/S1
7.5
25
18.5
1–15 (8)
GD35-011G-4-C1/D1/H1/H2/S1
11
32
25
1–1s5 (8)
GD35-015G-4-C1/D1/H1/H2/S1
15
40
32
1–15 (4)
GD35-018G-4-C1/D1/H1/H2/S1
18.5
47
38
1–15 (4)
GD35-022G-4-C1/D1/H1/H2/S1
22
56
45
1–15 (4)
