Goodrive100-PV Series Solar Pumping VFD Function parameters
32
Function
code
Name
Detailed illustration of parameters
Default
Modify
(rated frequency of motor1) or P04.05–
P02.16 (rated frequency of motor1)
Setting range of P04.08: 0.0%–110.0%
(rated voltage of motor1)
P04.09
V/F slip
compensation
gain
This function code is used to compensate
the change of the rotation speed caused
by load during compensation SVPWM
control to improve the rigidity of the motor.
It can be set to the rated slip frequency of
the motor which is counted as below:
△ f=f
b
-n*p/60
Of which, fb is the rated frequency of the
motor, its function code is P02.01; n is the
rated rotating speed of the motor and its
function code is P02.02; p is the pole pair
of the motor. 100.0% corresponds to the
rated slip frequency△ f.
Setting range: 0.0–200.0%
0.0%
○
P04.34
Two phase control
selection of
single-phase
motor
Ones: Reserved
Tens: Voltage of the secondary winding (V
phase) reverse
0: Not reversed; 1: Reversed
Setting range: 0–0x11
0x00
◎
P04.35
Voltage ratio of V
and U
0.00–2.00
1.40
○
P05 Group Input terminals
P05.00
HDI input type
0: High-speed pulse input. See P05.49–
P05.54.
1
◎
