INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
33
Function
code
Name
Detailed illustration of parameters
Default
Modify
1: HDI switch input
P05.01
S1 terminals
function selection
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and
A setting
15: Shift between combination setting and
B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
42
◎
P05.02
S2 terminals
function selection
43
◎
P05.03
S3 terminals
function selection
44
◎
P05.04
S4 terminals
function selection
45
◎
P05.05
S5 terminals
function selection
1
P05.09
HDI terminals
function selection
46
◎
