INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
39
Function
code
Name
Detailed illustration of parameters
Default
Modify
power
consumption
VFD power consumption = P07.15*1000 +
P07.16
Setting range of P07.15: 0–65535 (*1000)
Setting range of P07.16: 0.0–999.9
Unit: kWh
P07.16
LSB of VFD
power
consumption
●
P07.27
Current fault type
0: No fault
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
4: ACC overcurrent (OC1)
5: DEC overcurrent (OC2)
6: Constant-speed overcurrent (OC3)
7: ACC overvoltage (OV1)
8: DEC overvoltage (OV2)
9: Constant-speed overvoltage (OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: VFD overload (OL2)
13: Input side phase loss (SPI)
14: Output side phase loss (SPO)
15: Overheat of the boost module (OH1)
16: Overheat fault of the inverter module
(OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor antotune fault (tE)
21: EEPROM operation fault (EEP)
●
P07.28
Previous fault
type
●
P07.29
Previous 2 fault
type
●
P07.30
Previous 3 fault
type
●
P07.31
Previous 4 fault
type
●
P07.32
Previous 5 fault
type
●
P07.57
Previous 6 fault
type
●
P07.58
Previous 7 fault
type
●
P07.59
Previous 8 fault
type
●
P07.60
Previous 9 fault
type
●
P07.61
Previous 10 fault
type
●
P07.62
Previous 11 fault
type
●
