Goodrive20-EU series VFD Product overview
9
2.5 Name plate
Figure 2-1 Name plate
Note: These are name plate examples for the standard products. The mark such as
CE/TUV/IP20/UL will be applied according to the actual condition. The 1PH/3PH 220V models
of 2.2kW and lower and the 3PH 380V models of 11kW and lower have been UL certified.
Model: GD20-1R5G-S2-EU
Power(Output): 1.5kW
Input: AC 1PH 200V-240V 15.7A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 7.5A 0Hz-400Hz
S/N:
Model: GD20-015G-4-EU
Power(Output): 15kW
Input: AC 3PH 380V-480V 40A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 32A 0Hz-400Hz
S/N:
