Goodrive20-EU series VFD Peripheral options and parts
156
Note:
The rated derate voltage of the input reactor is 2%±15%.The rated derate voltage of the output
reactor is 1%±15%. Above options are external, the customer should indicate when
purchasing.
C.6 Filter
C.6.1 C3 Filter type instruction
BA C D E F
G
Character
designation
Detailed instruction
A
FLT: VFD filter series
B
Filter type
P: power supply filter
L: output filter
C
Voltage degree
S2: AC 1PH 200V – 240V
04: AC 3PH 380V – 480V
D
3-digit development serial number. For example, 003 stands for the serial
number of C3 filters in development
E
Installation type
L: Common type
H: High performance type
F
Utilization environment of the filters
A: the first environment (IEC61800-3:2004) category C1 (EN
61800-3:2004)
B: the first environment (IEC61800-3:2004) category C2 (EN
61800-3:2004)
C: the second environment (IEC61800-3:2004) category C3 (EN
61800-3:2004)
G
Lot No.
G: Special for external C3 filter
C.6.2 C3 filter
Goodrive20-EU series 1PH 220V/3PH 380V 2.2kW and below, 3PH 220V 0.75kW and below
models can satisfy the requirements of IEC61800-3 C3 as shown in the table below; 3PH
380V 4kW and above, 3PH 220V 1.5kW and above models can be set to satisfy the
requirements of IEC61800-3 C3 or not by jumper J10.
