INVT Goodrive20-EU VFD Series User Manual

Goodrive20-EU series VFD Keypad operation procedure
27
No.
Name
Description
1
State LED
RUN/TUNE
LED off – the VFD is stopped
LED blinking – the VFD is in parameter autotune
LED on – the VFD is running
FWD/REV
LED off – the VFD will run in the forward direction;
LED on – the VFD will run in the reverse direction
LOCAL/REMOT
LED indicates keypad operation, terminal operation
and remote communication control
LED off – the VFD is in keypad operation mode
LED blinking – the VFD is in terminal operation
mode
LED on – the VFD is in remote operation control
mode
TRIP
LED for faults
LED on – the VFD is faulty
LED off – normal state
LED blinking – the VFD is in pre-alarm, and will trip
soon without corrective actions
2
Unit LED
Mean the unit displayed currently
Hz
Frequency unit
RPM
Rotating speed unit
A
Current unit
%
Percentage
V
Voltage unit
3
Code
displaying
zone
5-figure LED display displays various monitoring data and alarm code
such as set frequency and output frequency.
Displayed
word
Corresponding
word
Displayed
word
Corresponding
word
Displayed
word
Corresponding
word
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
A
A
B
B
