INVT Goodrive20-EU VFD Series User Manual

Goodrive20-EU series VFD Function parameters
57
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.03
S3 terminal
function
selection
3: Tri-linear running control
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: Acceleration/deceleration time selection
terminal 1
22: Acceleration/deceleration time selection
terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Wobbling frequency pause (stop at present
frequency)
27: Wobbling frequency reset (return to center
frequency)
28: Counter reset
29: Torque control prohibition
30: Acceleration/deceleration prohibition
31: Counter trigger
32: Reserved
33: Cancel the frequency change setting
temporarily
7
◎
P05.04
S4 terminal
function
selection
0
◎
P05.05
S5 terminal
function
selection
0
◎
P05.06
S6 terminal
function
selection
0
◎
P05.07
S7 terminal
function
selection
0
◎
P05.08
S8 terminal
function
selection
0
◎
P05.09
HDI terminal
function
selection
0
◎
