INVT Goodrive20-EU VFD Series User Manual

Goodrive20-EU series VFD Function parameters
81
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
2: Valid during running, cleared after receiving
the stop command
LED thousands: ∧/∨ keys and analog
potentiometer integral function
0: The Integral function is valid
1: The Integral function is invalid
P08.43
Integral speed
ratio of keypad
potentiometer
0.01 – 10.00s
0.10s
○
P08.44
UP/DOWN
terminal control
setting
0x00 – 0x221
LED ones: frequency control selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting invalid
LED tens: frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: All frequency modes are valid
2: When the multi-step speed are priority, it is
invalid to multi-step speed
LED hundreds: action selection when stop
0: Setting is valid
1: Valid in running, clear after stop
2: Valid in running, clear after receiving the stop
commands
0x000
○
P08.45
UP terminal
frequency
increment
integral speed
ratio
0.01 – 50.00s
0.50 s
○
P08.46
DOWN
terminal
frequency
decrement
integral speed
ratio
0.01 – 50.00s
0.50 s
○
P08.47
Action
selection at
power loss
0x000 – 0x111
LED ones: Action of the digital regulation
frequency at power off.
0x000
○
