INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
128
Function
code
Name
Detailed instruction of parameters
Default
value
P02.02
Rated frequency of
asynchronous motor 1
0.01Hz–P00.03 (Max. output frequency)
50.00Hz
P02.03
Rated speed of
asynchronous motor 1
1–36000rpm
Depend
on model
P02.04
Rated voltage of
asynchronous motor 1
0–1200V
Depend
on model
P02.05
Rated current of
asynchronous motor 1
0.8–6000.0A
Depend
on model
P02.15
Rated power of
synchronous motor 1
0.1–3000.0kW
Depend
on model
P02.16
Rated frequency of
synchronous motor 1
0.01Hz–P00.03 (Max. frequency)
50.00Hz
P02.17
Number of poles pairs for
synchronous motor 1
1–50
2
P02.18
Rated voltage of
synchronous motor 1
0–1200V
Depend
on model
P02.19
Rated current of
synchronous motor 1
0.8–6000.0A
Depend
on model
P05.01–P05
.09
Multi-function digital input
terminals
(S1–S8,HDI) function
selection
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
P07.01
Parameter copy
The function code determines the
manner of parameters copy.
0: No operation
1: Upload the local function parameter to
the keypad
2: Download the keypad function
parameter to local address (including the
motor parameters)
3: Download the keypad function
parameter to local address (excluding the
motor parameter of P02 and P12 group)
4: Download the keypad function
parameters to local address (only for the
motor parameter of P02 and P12 group)
0
P07.02
QUICK/JOG function
0: No function
1
