INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
183
Function code
Name
Detailed instruction of parameters
Default
value
P00.03
Max. output
frequency
P00.03–400.00Hz
50.00Hz
P00.06
A frequency
command
0: Keypad
1: AI1
2: AI2
3: AI3
4:High-speed pulse HDI
5:Simple PLC program
6: Multi-step speed running
7: PID control setting
8: Modbus communication setting
9: PROFIBUS/CANopen communication
setting
10: Ethernet communication
setting(reserved)
11: Reserved
0
P00.11
ACC time 1
0.0–3600.0s
Depend
on model
P00.12
DEC time 1
0.0–3600.0s
Depend
on model
P05.01–P05.09
Digital input
function
selection
26:Traverse Pause (stop at the current
frequency)
27:Traverse reset (return to the center
frequency)
P08.15
Traverse range
0.0–100.0% (corresponding to the set
frequency)
0.0%
P08.16
Sudden jumping
frequency range
0.0–50.0% (corresponding to the traverse
range)
0.0%
P08.17
Traverse boost
time
0.1–3600.0s
5.0s
P08.18
Traverse
declining time
0.1–3600.0s
5.0s
7.17 Pulse counter
Goodrive300 series VFDs support pulse counter which can input counting pulse through HDI terminal.
When the actual length is longer than or equal to the set length, the digital output terminal can output
length arrival pulse signal and the corresponding length will clear automatically.
