INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
147
Function
code
Name
Detailed instruction of parameters
Default
value
P12.21
Direct axis inductance of
synchronous motor 2
0.01–655.35mH
Depend
on model
P12.22
Quadrature axis
inductance of
synchronous motor 2
0.01–655.35mH
Depend
on model
P12.23
Back EMF constant of
synchronous motor 2
0–10000
300
7.7 Start-up and stop control
The start-up and stop control of the VFD includes three states: start after the running command during
normal powering on, start after the restarting function becomes valid during normal powering on and
start after the automatic fault reset. Below is the detailed instruction for three startings.
There are three starting methods for the VFD: start from the starting frequency directly, start after the
AC braking and start after the rotation speed tracking. The user can select according to different
situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is better
to select starting after DC braking and then starting after rotation speed tracking.
Note: it is recommended to use the direct starting to drive synchronous motor.
1. The starting logic figure of starting after the running command during the normal powering on.

INVT Goodrive300 Series Specifications

General

Brand	INVT
Model	Goodrive300 Series
Category	DC Drives
Language	English
