INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Dimension drawings
256
Model
W1
W2
W3
W4
H1
H2
D1
D2
Installation
hole
Weight
(kg)
220kW–280kW
750
230
714
680
1410
1390
380
150
13\12
135
315kW
750
230
714
680
1410
1390
380
150
13\12
137
350kW–500kW
620
230
573
\
1700
1678
560
240
22\12
410
C.5 Dimensions for VFDs of AC 3PH 380V (-10%)–550V (+10%)
C.5.1 Wall installation
Wall installation of 500V 4-18.5kW VFDs
Wall installation of 500V 22-75kW VFDs
Installation dimension (unit:mm)
Model
W1
W2
H1
H2
D1
Installation
hole
Weight
(kg)
4kW–18.5kW
170
151
331.5
303.5
216
6
6
22kW–55kW
270
130
555
540
325
7
30
75kW
325
200
680
661
365
9.5
47
