INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
140
Function
code
Name
Detailed instruction of parameters
Default
value
P00.00
Speed control
mode
0: Sensorless vector control mode 0 (applicable
to AM and SM)
1: Sensorless vector control mode 1 (applicable
to AM)
2: SVPWM control mode (applicable to AM and
SM)
1
P03.11
Torque setting
method
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS\CANopen communication setting
torque
9: Ethernet communication setting torque
10: Reserved
0
P03.12
Keypad setting
torque
-300.0%–300.0%
(rated current of the motor)
50.0%
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
P03.14
Upper frequency of
forward rotation in
vector control
0: Keypad (P03.16 sets P03.14, P03.17 sets
P03.15)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication setting upper-limit
frequency
7: PROFIBUS/CANopen communication setting
upper-limit frequency
8: Ethernet communication setting upper-limit
frequency
0
P03.15
Upper frequency of
reverse rotation in
vector control
0
