INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
155
Function
code
Name
Detailed instruction of parameters
Default
value
5.09
terminals
(S1–S8, HDI) function
selection
11: Decreasing frequency setting
(DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
and B setting
P08.42
Keypad data control
0x000–0x1223
LED ones: frequency enable selection
0: Both ∧ / ∨ keys and digital
potentiometer adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only digital potentiometer adjustments
is valid
3: Neither ∧ / ∨ keys nor digital
potentiometer adjustments are valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or
P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when
multi-step speed has the priority
LED hundreds: action selection during
stopping
0: Setting is valid
1: Valid during running, cleared after
stopping
2: Valid during running, cleared after
receiving the stop command
LED thousands: ∧/∨ keys and digital
potentiometer Integral function
0: The Integral function is valid
1: The Integral function is invalid
0x0000
P08.43
Integral ratio of the keypad
potentiometer
0.01–10.00s
0.10s
P08.44
UP/DOWN terminals
control
0x00–0x221
LED ones: frequency control selection
0x000
