INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
168
Function
code
Name
Detailed instruction of parameters
Default
value
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
P05.13
Terminals control running
mode
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0
P05.14
Switch-on delay of S1
terminal
0.000–50.000s
0.000s
P05.15
Switch-off delay of S1
terminal
0.000–50.000s
0.000s
P05.16
Switch-on delay of S2
terminal
0.000–50.000s
0.000s
P05.17
Switch-off delay of S2
terminal
0.000–50.000s
0.000s
P05.18
Switch-on delay of S3
terminal
0.000–50.000s
0.000s
P05.19
Switch-off delay of S3
terminal
0.000–50.000s
0.000s
P05.20
Switch-on delay of S4
terminal
0.000–50.000s
0.000s
P05.21
Switch-off delay of S4
terminal
0.000–50.000s
0.000s
P05.22
Switch-on delay of S5
terminal
0.000–50.000s
0.000s
P05.23
Switch-off delay of S5
terminal
0.000–50.000s
0.000s
P05.24
Switch-on delay of S6
terminal
0.000–50.000s
0.000s
P05.25
Switch-off delay of S6
terminal
0.000–50.000s
0.000s
