INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Peripherial options and parts
269
D.5.1 The VFDs of AC 3PH 380V (-15%)–440V(+10%)
Model
Fuse (A)
Breaker (A)
The rated working
current of the
contactor(A)
GD300-1R5G-4
15
16
10
GD300-2R2G-4
17.4
16
10
GD300-004G-4
30
25
16
GD300-5R5G-4
45
25
16
GD300-7R5G-4
60
40
25
GD300-011G-4
78
63
32
GD300-015G-4
105
63
50
GD300-018G-4
114
100
63
GD300-022G-4
138
100
80
GD300-030G-4
186
125
95
GD300-037G-4
228
160
120
GD300-045G-4
270
200
135
GD300-055G-4
315
200
170
GD300-075G-4
420
250
230
GD300-090G-4
480
315
280
GD300-110G-4
630
400
315
GD300-132G-4
720
400
380
GD300-160G-4
870
630
450
GD300-200G-4
1110
630
580
GD300-220G-4
1230
800
630
GD300-250G-4
1380
800
700
GD300-280G-4
1500
1000
780
GD300-315G-4
1740
1200
900
GD300-350G-4
1860
1280
960
GD300-400G-4
2010
1380
1035
GD300-500G-4
2505
1720
1290
Note: The accessory specifications described in the preceding table are ideal values. You can select
accessories based on the actual market conditions, but try not to use those with lower values.
D.5.2 AC 3PH 380V(-10%)V–550V(+10%)
Model
Fuse (A)
Breaker (A)
The rated working
current of the
contactor(A)
GD300-004G-5
30
25
16
GD300-5R5G-5
30
25
16
GD300-7R5G-5
45
25
16
