Inxpect SBV System Series User Manual

70
SBV System Series| Instruction manual v1.2 DEC 2021 |SAF-UM-SBVBus-en-v1.2|© 2021 Inxpect SpA
7. Maintenance and troubleshooting
Event Type
Modbus connection INFO
Session authentication INFO
Validation INFO
Log download INFO
For further information about the events, see "INFOevents" on the next page and " ERRORevents (control unit)"
on page73.
7.2.7 Verbosity level
There are six verbosity levels for the log. The verbosity can be set during the configuration of the system via the
Inxpect Safety application (Settings > Activity History > Log verbosity level).
Depending on the selected verbosity level, the events are logged in accordance to the following table:
Event
Level 0
(default)
Level 1 Level 2 Level 3 Level 4 Level 5
Diagnostic errors x x x x x x
System Boot
x x x x x
x
System configuration
x x x x x
x
Factory reset x x x x x x
Stop signal
x x x x x
x
Restart signal
x x x x x
x
Detection access - See "Verbosity level for detection access and exit events"
below
Detection exit - See "Verbosity level for detection access and exit events"
below
Dynamic configuration in
use
- - - - x x
Muting status - - - - - x
7.2.8 Verbosity level for detection access and exit events
Depending on the selected verbosity level, the detection access and exit events are logged as follows:
l LEVEL0: no detection info is logged
l LEVEL 1: the events are logged at control unit level and the additional information are the detection
distance (in mm) and the detection angle (°) in detection access.
Format:
CONTROL UNIT Detection access (distance mm/azimuth°)
CONTROL UNIT Detection exit
l LEVEL 2: the events are logged in a single field at control unit level and the additional information are:
detection field, detection distance (in mm) and detection angle (°) in access, and detection field at exit.
Format:
CONTROL UNIT Detection access (field #n, distance mm/azimuth°)
CONTROL UNIT Detection exit (field #n)
l LEVEL 3 / LEVEL 4 / LEVEL 5 The events are logged:
o
in a single field at control unit level and the additional information are: detection field, detection
distance (in mm) and detection angle (°) in access, and detection field at exit;
o
at sensor level and the additional information read by the sensor are: detection distance (in mm) and
detection angle (°) in access, and detection field at exit.
Format:
CONTROL UNIT #k Detection access (field #n, distance mm/azimuth°)
SENSOR #k Detection access (distance mm/azimuth°)
