Inxpect SBV System Series User Manual

4. Wait until all the six LEDs on the control unit turns steady green: the Ethernet parameters are set to their
default values (see "Ethernet connection (if available)" on page79).
5. Configure the control unit again.
6.3 Validate the safety functions
6.3.1 Validation
Once the system has been installed and configured, check that the safety functions are activated/deactivated as
expected and that the dangerous area is monitored by the system.
WARNING! The Inxpect Safety application facilitates installation and configuration of the system,
but the validation process described below is still required.
6.3.2 Validate the access detection function
Example 1
Starting conditions l Detection field dependency: Dependent mode
l All the safety outputs activated
Validation
procedure
1. Access the first detection field .
2. Check that the system deactivates the safety output related to this detection field
and to the following fields. See "Validate the system with Inxpect Safety" on page61.
3. Move inside the area and check that the target position moves in the Inxpect Safety
app.
4. Repeat step 1 and 3 for each detection field .
5. If the safety outputs are not deactivated, see "Troubleshooting validation" on
page61.
Specifications l Access from several points with particular attention to the side areas of the field of
view and the limit areas (e.g. intersection with any side guards), see "Example of
access points" on the next page.
l Access standing as well as crawling.
l Access moving slowly and quickly.
Example 2
Starting conditions l Detection field dependency: Independent mode
l All the safety outputs activated
Validation
procedure
1. Access the first detection field .
2. Check that the system deactivates only the safety output related to this detection
field. See "Validate the system with Inxpect Safety" on page61.
3. Move inside the area and check that the target position moves in the Inxpect Safety
app.
4. Repeat step 1 and 3 for each detection field .
5. If the safety outputs are not deactivated, see "Troubleshooting validation" on
page61.
Specifications l Access from several points with particular attention to the side areas of the field of
view and the limit areas (e.g. intersection with any side guards), see "Example of
access points" on the next page.
l Access standing as well as crawling.
l Access moving slowly and quickly.
6. Installation and use procedures
SBV System Series| Instruction manual v1.2 DEC 2021|SAF-UM-SBVBus-en-v1.2|© 2021 Inxpect SpA
59
